Fortron Source Twins 700W

PS/2 Power Supplies - Redundant

PRODUCT FEATURES

// PS/2 Power Supplies - Redundant
// 700 W

Prices and delivery times are visible to registered and logged-in customers. New customers can request this information without obligation.

Sales only to business customers.
Delivery time: upon request

Basic Module: Fortron Source Twins 700W

General information
	SKU / Item Number			Twins 700W
Product Basic Data
	Manufacturer			Fortron Source
Power Supply
	Typ (Input)	AC	Range	100~240V
			Input frequency	50-60 Hz
			Modules	2 Pce
	Power supply - Input			AC: 100-240V
	Output wattage			700 W
	Output Voltage	+5V	Output Current Max	20 A
		-12V	Output Current Max	0,5 A
		+3.3V	Output Current Max	20 A
		+5V Standby	Output Current Max	3 A
		+12V1	Output Current Max	16 A
		+12V2	Output Current Max	16 A
		+12V3	Output Current Max	16 A
	Efficiency	At 100% load / 25°C		80 %
Mechanical / Environment
	Temperature	Operation		0° to 50°C
		Storage		-20° to 80°C
	Relative humidity	Operation		5 to 90%, non-condensing
		Storage		5 to 90%, non-condensing
	Dimensions	Form factor		PS/2 Redundant
		Width		150 mm
		Deep		190 mm
		Height		86 mm
	Weight			2850 g
	MTBF (Mean Time Between Failures)	MTBF at 25°C		100.000 h
	Color			Black
Certificates / Conformities
	CE			Yes
	UL			Yes
	FCC	Class B		Yes
	CCC			Yes
	Additional certificates / compliance approvals			80 PLUS Gold, IEC 60950-1
