Intel U300E

U Series

PRODUCT FEATURES

// Intel U300E
// 1,10 GHz
// 8 MB Cache
// BGA 1744

Prices and delivery times are visible to registered and logged-in customers. New customers can request this information without obligation.

Sales only to business customers.
Delivery time: upon request

Basic Module: Intel U300E

General information
	SKU / Item Number		U300E
Product Basic Data
	Manufacturer		Intel
	Product ID		FJ8071505225904
System
	Processor	Vertical Segment	Embedded
		Series	Intel Raptor Lake
		Number	Intel U300E
		CPU cores	5 Pce
		Threads	6 Pce
		Socket	BGA 1744
		Base frequency	1,1 GHz
		Performance Core Max Turbo Frequency	4,3 GHz
		Efficient-core Max Turbo Frequency	3,2 GHz
		Cache	8 MB
		Thermal Design Power (TDP)	15 W
		Maximum Turbo Power Consumption	55 W
		Lithography	10 nm
		Spec Code	SRMNJ
	Memory	Maximum expansion	96 GB
		ECC (Error-Correcting Code)	not supported
Graphics
	Processor		Intel UHD Graphics
	Performance feature	Support	DirectX 12.1, OpenCL 3.0, OpenGL 4.6
	Screens (Multi-display)		4 displays
Extension
	PCI Express version		4.0
	Max. PCI Express lanes		20 Pce
Mechanical / Environment
	Temperature	Operation	100°C
	Dimensions	Width	50 mm
		Deep	25 mm
Certificates / Conformities
	CE		Yes
	RoHS compliant		Yes
